TSI7900 R&D SHIELDED ENCLOSURE
TSI7900 R&D SHIELDED ENCLOSURE
The TSI7900 RF Shielded Test Enclosure from Technostrom Innovations Private Limited is a high-performance solution tailored for EMI, RFI, and wireless communication testing needs. Engineered for exceptional shielding efficiency, it ensures reliable testing even in the most sensitive RF environments, offering over 90dB shielding effectiveness. Designed with spacious interiors, the TSI7900 accommodates larger devices without compromising performance. Its versatile configuration options and customizable design elements make it ideal for engineers working across R&D, product development, and production testing. Experience unmatched precision in RF testing with this robust, adaptable shielded enclosure.
Features
- EMI filters on Data Ports and Power lines
- User Defined & Interchangeable I/O Connector options
- RF Gasket System
- Design and Develop for Wireless Device Testing
- Completely Customizable Shielded Enclosure
- High Performance RF Absorber lining
- Rugged Welded Construction
- High performance shielded Air Vents for adequate air flow
Applications
- R&D and Quality Assurance Tests
- Wireless Device Testing
- Wi-Fi 802.11 - All series
- Bluetooth and Zigbee
- Forensics and Security
- Cellular 4G,5G,LTE, Wimax
- Wireless Medical Device
Highlights
SHIELDING EFFECTIVENESS (ISOLATION)
- 85dB @ 20 MHz ~ 1 GHz
- 90dB @ 1 GHz ~ 3 GHz
- 95dB @ 3 GHz ~ 6 GHz
- 85dB @ 6 GHz ~ 12 GHz
DIMENSION
- Exterior : 22″H x 59″W x 35″D
- Interior : 20″H x 57″W x 33″D
Fill The Form Below
LBX7900 Shielded Enclosure comes with the following
- RF Ports : SMA Bulkhead Connector
- Filtered USB 3.0
- Filtered Ethernet 10M, 100M, 1G & 10G
- AC Power line Filter Voltage Range 110 ~ 270V - 50/60 Hz
- DC Power - 5A Jack Connector
- Honeycomb Air Vents 120 mm x 120 mm
- 1” RF Absorber for dampening internal signal reflections
- Higher CFM Fan size of 120mm
- Base wooden plate to place DUT
- IEC Power cords
- Belkin Power Strip 6 Way Universal Sockets
USER-DEFINED - I/O OPTION
- Filtered Ethernet - 10M, 100M, 1G & 10G
- Filtered USB 2.0 & 3.0 –C Type
- AC / DC Power line filter
- RF Ports: SMA, N Type, BNC, TNC
- Fiber optics: ST & Waveguide
- Data: DB9, DB15, DB25, DB50, RJ11
- Filtered HDMI, VGA & Audio Ports
